SprintIR-6S Fast Response
Contact our experienced engineers to discuss your application needs.
Details
- Accurately detects COâ‚‚ concentrations up to 100%
- Designed for minimal power consumption, ideal for portable and battery-operated devices
- Employs solid-state LED optical sensing for long-term reliability
- Robust construction offers resistance to shock and vibration
- UART communication interface ensures straightforward system integration
- Includes built-in auto-calibration for consistent, long-term performance
SprintIR®-6S-100 CO₂ Sensor (formerly GC-0030) is a high-speed sensor engineered for demanding applications such as fire suppression testing and safety monitoring. It captures up to 20 CO₂ readings per second, delivering rapid and reliable data acquisition.
The sensor includes a standard flow-through adaptor, allowing COâ‚‚ gas to move swiftly across the optical element for high-speed measurements.
Powered by patented NDIR solid-state LED optical technology, the SprintIR®-6S-100 is designed to detect rapidly fluctuating CO₂ concentrations without compromising measurement accuracy or performance.
The sensor includes a standard flow-through adaptor, allowing COâ‚‚ gas to move swiftly across the optical element for high-speed measurements.
Powered by patented NDIR solid-state LED optical technology, the SprintIR®-6S-100 is designed to detect rapidly fluctuating CO₂ concentrations without compromising measurement accuracy or performance.
Supply voltage
-0.3V - +6.0V
Voltage Range Digital Inputs
GND -0.3V - 5V
Storage Temperature Range
-40°C - +70°C
Humidity Range (RH)
0 - 95%
Operating Pressure Range
500mbar - 10bar
